AI Agents

The ai-agent block lets an LLM accomplish a task by calling flow branches as tools, in a loop. You describe the task in a prompt and give the model tools built from ordinary process chains; the block folds the model's final answer back into the message.

A complete example

This flow enriches an inbound lead. The agent calls the classify_size tool as needed, then answers with a JSON object that becomes the message body.

service:
  name: ai-agent

env:
  - name: ANTHROPIC_API_KEY
    required: true

connectors:
  - name: claude
    type: llm-anthropic
    settings:
      apiKey: ${ANTHROPIC_API_KEY}

flows:
  - name: enrich
    process:
      - type: ai-agent
        name: enrich-lead
        connector: claude
        maxIterations: 6
        prompt: >
          Enrich the inbound lead. Classify the company size and decide whether
          it is a good fit. Call the tools as needed, then respond with a JSON
          object {"tier": "...", "fit": true|false}.
        guardrail: >
          If you cannot classify the lead with confidence, take the default path.
        tools:
          - name: classify_size
            description: Classify a company's size tier from its name and domain.
            inputSchema: |
              {
                "type": "object",
                "required": ["company"],
                "properties": {
                  "company": { "type": "string" },
                  "domain":  { "type": "string" }
                }
              }
            process:
              # A real tool would call an API; here we just echo a tier so the
              # sample runs without external dependencies.
              - type: set-payload
                settings:
                  value: '{"tier": "smb"}'
        default:
          process:
            - type: set-payload
              settings:
                value: '{"status": "needs-manual-review"}'

Run it with the CLI:

export ANTHROPIC_API_KEY=sk-ant-...
octo invoke --config samples/ai-agent.yaml --flow enrich \
  --data '{"company":"Acme","domain":"acme.example"}'

ai-agent is a composite block: connector, prompt, tools and the other keys sit at the top level of the block, not under settings:.

How the loop works

1. The block encodes the incoming message body as JSON and hands it to the model as the task input.
2. The model calls tools as needed. Each call's arguments become the tool branch's message body; the branch's output body is returned to the model as the tool result.
3. Tool branches share the message, so variables a branch sets are visible to later tools and to the rest of the flow.
4. When the model stops calling tools, its final text is folded into the message body: parsed as JSON when possible, stored as text otherwise. An empty final answer leaves the body as the last tool left it.

Each iteration is one model call. maxIterations caps the loop (default 8); an agent that never finishes within the cap takes the default path. A tool branch that errors returns the error text to the model as a failed tool result, so the model can retry with different arguments, try another tool, or take the guardrail.

Fields

Guardrail and the default path

The guardrail text is appended to the system prompt as guidance on when to stop trying. The default flow runs when the model refuses the task or the loop exceeds maxIterations without a final answer, and receives the current message, including variables tool branches set.

Input and output

The agent's input is the message body when the block runs; the model sees exactly that JSON, so shape it with a transform first. Its output is the message body after the block; ask for a specific JSON shape (as the example does) and downstream blocks can rely on it. A markdown code fence around the answer is stripped before parsing.

Sending files

An agent can be handed a screenshot, a scanned invoice or a voice note instead of a description of one. Two settings do it — input states the question, and attachments says which part of the body holds the files:

- type: ai-agent
  name: describe-file
  connector: claude
  answer: text
  input: body.question
  attachments: 'has(body.files) ? body.files : []'
  prompt: Answer the user's question about the attached files.
  tools: [...]


input is required here rather than optional. The default opening turn is the whole body as a JSON document, so a flow that left it unset would send every file twice: once as a file the model can read, and once as a base64 string in the middle of the prompt. The block refuses to build instead, because that version works and quietly bills for every byte twice.

The files ride one turn. The model reads them on the first model call and they are dropped from the transcript as soon as it returns, so tool calls and follow-ups are text and a stored conversation never holds the bytes. See attachments for keepAttachments, responseMedia, and which files each provider accepts.

The full sample is samples/ai-agent-attachments.yaml:

export ANTHROPIC_API_KEY=sk-ant-...
octo invoke --config samples/ai-agent-attachments.yaml --flow describe \
  --data '{"question":"What is in this image?","files":[{"mimeType":"image/png","name":"red.png","data":"iVBORw0KGgoAAAANSUhEUgAAAAEAAAABCAIAAACQd1PeAAAADElEQVR4nGP4z8AAAAMBAQDJ/pLvAAAAAElFTkSuQmCC"}]}'

Next steps

• Memory across invocations.
• Sending files to an agent, and what each provider accepts.
• Steer or stop a run in flight.
• Skills and reusable flow-backed tools for larger agents.
• A production agent end to end: the Slack agent capstone.
• Full field tables: AI Blocks reference.
