Event Bus
How the orchestrator and runtimes coordinate over NATS.
One NATS broker is the platform's message backbone. Control-plane events, runtime work queues, and log shipping all share it — separated by subject namespace, never by broker. This page maps what flows over it and how events reach the browser.
Subject map
| Subject | Publisher | Consumer | Purpose |
|---|---|---|---|
internal.deployments.{integrationId} | orchestrator | platform BFF (per-integration SSE) | Deployment status snapshots |
internal.integrations.events | platform BFF (MCP writes) | platform BFF (SSE) | Integration-write live-reload hints |
internal.logs | every runtime pod | log aggregator (queue group) | Structured log shipping |
octo.{deploymentId}.q.{subject} | runtime pods | runtime pods (queue group) | Flow queues — competing consumers |
octo.{deploymentId}.t.{subject} | runtime pods | runtime pods (plain subscribe) | Flow topics — broadcast fan-out |
The convention: control-plane infrastructure lives under internal.*; runtime messaging is scoped per deployment under octo.{deploymentId}.*, so deployments sharing the broker can never collide with each other or with the platform's own traffic.
Orchestrator events: deployment status
The orchestrator runs Kubernetes informers over the deployments and pods it manages. On every cluster change it recomputes the affected integration's full deployment list — the same JSON array the REST list endpoint returns — and publishes it to internal.deployments.{integrationId} (fire-and-forget: a broker hiccup is logged, never blocks the write path).
On the other side, the platform BFF holds a single lazily opened NATS connection. Its SSE route (GET /api/integrations/{id}/deployments/events) subscribes to the integration's subject and relays each snapshot to the browser as a Server-Sent Events frame. Because the fan-out goes through NATS rather than process memory, it works across multiple platform replicas — whichever replica serves the SSE request sees every snapshot.
Snapshots carry the same wire shape as the REST response on purpose: the browser parses a streamed frame and a polled response identically, so degrading to polling is seamless.
Integration-write events
When an MCP client creates or updates an integration, the BFF publishes an integration.updated event (the integration's id and name) so an editor with that integration open can live-reload it. With NATS configured the event goes to internal.integrations.events and reaches editors on any replica; the SSE route GET /api/integrations/events relays it. Delivery is fire-and-forget by contract — an MCP write never fails because the reload hint couldn't be delivered.
The in-process fallback (packages/events)
@octo/events is a tiny shared package: the OctoEvent types, an in-process publish/subscribe bus, an SSE Response builder, and the browser EventSource client. When NATS_URL is unset or the broker is unreachable — the standalone app, local development, a single-replica deploy without a broker — the BFF publishes on this in-process bus instead, which reaches editors connected to the same process. The subscription API the browser sees is identical either way.
Degradation without a broker
Everything on this page is optional infrastructure:
- The orchestrator's publisher is a noop when
NATS_URLis unset — writes and deploys work unchanged. - The deployments SSE route answers
503, and the browser falls back to polling the REST list. - Integration-write events fall back to the in-process bus.
- Runtime queues, topics, and log shipping do require NATS in clustered runs — the k8s services module refuses to start a pod without
NATS_URL, surfacing the misconfiguration at startup rather than on first use.
The chart deploys NATS by default (nats.enabled) as core NATS — ephemeral fan-out with no JetStream persistence. Events are live signals, not a durable event log: a subscriber that wasn't connected simply catches up from the REST API.
Relationship to runtime messaging
The runtime's queue and topic constructs (see Clustering) use the same broker through the same injected NATS_URL, but they are user-level messaging between a deployment's replicas — deployment-scoped subjects, queue groups for competing consumers, native request–reply — while the internal.* subjects are platform plumbing. A flow never sees platform events, and platform components never consume flow queues.
